ORCAS 1700C Polycrystalline Mullite Ceramic Fiberboard
- $11.00 /kilogram
- 1 kilogram
- Zhejiang Orcas Refractories Co., Ltd.
- Zhejiang, China
- Ms Michelle Shen
Product Detail
| Shrinkage (1800℉, 3 hours): | 2% | width: | 600/1000mm |
| Fiber Diameter: | 3.5um | usage: | Industrial furnace |
| brand: | Killer Whale | chemical composition: | Al2O3+SiO2 |
| application: | refractory | density: | 500 |
| port: | Shanghai/Ningbo | Feature 2: | heat resistance |
| length: | 900/1000mm | Supply capacity: | 100,000 kg per month |
| Packaging Details: | Carton/wooden box/pallet | Thermal Conductivity: | 0.085-0.2 |
| type: | Ceramic Fiber Insulation Products | port: | Shanghai/Ningbo/Yiwu |
| payment terms: | L/C, T/T, Western Union, MoneyGram | thickness: | 25-150mm |
| quality: | high quality | model: | AK-74 |
| color: | pure white | MOQ: | 1 |
| grade: | ST (Standard) | size: | customer request |
| Ultimate Strength (≥MPa): | 0.25 | product name: | Polycrystalline Mullite Ceramic Fiber Board |
| Operating temperature: | Up to 1550C | place of origin; place of origin: | China |
| Package preview: |
Polycrystalline mullite fiberboardIt is made of polycrystalline mullite fiber cotton compressed by wet vacuum suction filtration process with organic and inorganic binders. Fiberboard has the characteristics of good strength, erosion resistance, easy processing, and easy cutting. As a multi-purpose product, polycrystalline mullite fiberboard can be applied to the high-temperature heating surface of the furnace lining.
thing | AK-54 | AK-64 | AK-74 | AK-84 | |||
Grading temperature (°C) | 1500 | 1600 | 1700 | 1800 | |||
Working temperature (℃) | ≤1350 | ≤1450 | ≤1550 | ≤1650 | |||
Heating linear change (%) | 1250℃*24H≤-3 | 1400℃*24H≤-3 | 1500℃*24H≤-1 | 1600℃*24H≤-0.8 | |||
Density (kg/m33) | 400-600 | ||||||
Al2Europe3(%) | ≥63 | ≥69 | ≥80 | ≥83 | |||
silica2+ aluminum2Europe3(%) | ≥99 | ≥99 | ≥99 | ≥99 | |||
iron2Europe3(%) | / | / | / | / | |||
Zirconia2(%) | / | / | / | / | |||
Dimensions (mm) | 1000/900*600*(5-150) | ||||||
feature
Low heat capacity and low thermal conductivity
Non-brittle material, good elasticity
excellent thermal stability
Anti-wind erosion, long service life
Excellent thermal shock resistance
Excellent anti-stripping performance
Easy to shape and cut
Non-brittle material, good elasticity
excellent thermal stability
Anti-wind erosion, long service life
Excellent thermal shock resistance
Excellent anti-stripping performance
Easy to shape and cut
application
High temperature gasket
Anti-scour area inside the lining
High temperature furnace lining hot surface material
Heating device insulation
Furnace door and furnace filling materials
Anti-scour area inside the lining
High temperature furnace lining hot surface material
Heating device insulation
Furnace door and furnace filling materials
equipment
We have our own mixer, drying room, calciner, grinder, cutter, engraver, laboratory, etc. Plates of different sizes, densities, and operating temperatures can be customized. OEM is welcome.
Zhejiang Aukas Refractories Co., Ltd.Founded in 2014, it specializes in the R&D, production and sales of new energy-saving refractory materials. With strong technical force and economic strength, our advanced products are widely used in metallurgy, construction, electric power, chemical industry, casting, glass, kiln and other industries.
Orcas main products include polycrystalline mullite fiber series, ceramic fiber cotton, blanket, board, paper, module, special-shaped parts, furnace, textile and airgel blanket, etc.
In the spirit of honesty, harmony, efficiency and enthusiasm, we sincerely hope to cooperate with your company.
Orcas main products include polycrystalline mullite fiber series, ceramic fiber cotton, blanket, board, paper, module, special-shaped parts, furnace, textile and airgel blanket, etc.
In the spirit of honesty, harmony, efficiency and enthusiasm, we sincerely hope to cooperate with your company.
