Aluminum Silicate Vacuum Formed Ceramic Fiber Board for Thermal Insulation

Product Detail

sample:usableUltimate Strength (≥MPa):0.5
Thermal Conductivity:0.085-0.18w/(mk)brand:Centrum
application:insulationCertificate:BV, SASO, ROHS, SGS, CE, ISO9001:2000
chemical composition:Alumina: 47-49%density:220-600kg/m3
Operating temperature:1100°Ccolor:pure white
place of origin; place of origin:Shandong ChinaPackaging Details:carton
grade:HP (high purity)payment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGram, Cash, Paypal
port:QingdaoMSDSs are available:yes
model:High puritysize:According to customer requirements
Supply capacity:50 tons per day
Product Description
SUNTHERM Vacuum Formed Ceramic Fiber

Using ceramic fiber as the main raw material, after fiber processing, slag removal, adding a certain amount of organic and inorganic binders, high-strength fiberboard is made by vacuum forming process. Products are divided into: ordinary, high-purity, high-alumina, zirconium-type ceramic fibers.


application

• Applications requiring high temperature toughness, high strength in load bearing areas
• For high air flow, extensive mechanical damage to industrial furnace wall linings, door and roof seals
• Building, fire door, fire wall fire insulation
• High temperature pipe wall lining
• High temperature furnace insulation
• High temperature resistant gasket
• Glass tank furnace insulation board
• Furnace top insulation
• Molten metal delivery system
• Combustion chamber insulation
• Ladle lining
• Shipping, aviation, precision industrial equipment

feature

•Low heat capacity, low thermal conductivity
• Non-brittle material with good elasticity
• Anti-wind erosion, long service life
• Excellent thermal stability and thermal shock resistance
• Acoustic performance
• Rigid, free support
• Good peeling resistance
•Easy to shape or cut
• High strength and excellent processability
• Dimensions can be accurate to ±2mm

Product parameters
detailed drawing
customer photo
