Factory direct sales of corrosion-resistant furnace quartz tube quartz tube price
-
$20.00 / 1 - 49 pieces
$14.90 / 50 - 999 pieces
$14.50 / >=1000 pieces - 1 piece
- Lianyungang Shengfan Quartz Products Co., Ltd.
- Jiasngsu, China
- Mr SHARON
Product Detail
| port: | Shanghai and Qingdao ports | Surface treatment: | polishing |
| density: | 2.2 g/cm3 | shape: | Double tube |
| Processing services: | Bending, welding, cutting, forming | color: | transparent |
| Supply capacity: | 10000 pieces per month | Softening Point: | 1730C |
| purity: | 99.999% | payment terms: | L/C, T/T |
| application: | Heating Tube Furnace Tube | model: | QSP-535 |
| Ozone content: | Ozone free | Outer diameter: | 0.5-100mm |
| product name: | Quartz glass tube | size: | custom size |
| Processing: | Accept quartz tube customization | Operating temperature: | 1100°C |
| length: | 10-2500mm | Packaging Details: | Plastic Bubble/Styrofoam Board/Carton/Wooden Pallet |
| place of origin; place of origin: | Jiangsu, China | Package preview: | |
| brand: | Raw sail | Material: | silica |
| Types of: | Clear Quartz Tube |
Product Description
Features of quartz tube/quartz glass tube:
1. High purity: 99.99%-99.999% SiO2.
2. Strong hardness: Mohs hardness 5.3-6.5.
3. High temperature resistance: it can work continuously below 1200°C,
4. Acid and alkali resistance: Quartz glass does not react with any acid and alkali except hydrofluoric acid. Its stability is 30
150 times that of ceramics and 150 times that of stainless steel
4. Electrical insulation: 10,000 times that of ordinary glass.
5. High light transmittance: 85%-95%, depending on different spectra.
6. Excellent thermal shock stability: small thermal expansion coefficient, 5.5×10-7/℃.
2. Strong hardness: Mohs hardness 5.3-6.5.
3. High temperature resistance: it can work continuously below 1200°C,
4. Acid and alkali resistance: Quartz glass does not react with any acid and alkali except hydrofluoric acid. Its stability is 30
150 times that of ceramics and 150 times that of stainless steel
4. Electrical insulation: 10,000 times that of ordinary glass.
5. High light transmittance: 85%-95%, depending on different spectra.
6. Excellent thermal shock stability: small thermal expansion coefficient, 5.5×10-7/℃.
Compressive strength | >1100Mpa | Thermal expansion coefficient | 5.5x10-7 cm/cm. ℃ |
Bending strength | 67Mpa | Melting temperature | 1750~1800℃ |
tensile strength | 48.3Mpa | short temperature | 1500℃ |
Poisson's ratio | 0.14~0.17 | prolonged temperature | 1200°C to 1300°C |
Elastic Modulus | 71700Mpa | Resistivity | 7x107.2.cm |
Shear modulus | 31000Mpa | Dielectric strength | 250~400Kvicm |
Moh's hardness | 5.3~6.5 (Mohs scale) | Dielectric constant | 3.7~3.9 |
inflection point | 1650°C | Dielectric absorption coefficient | <4x104 |
Specific heat (20~350℃) | 670J/kg℃ | Dielectric Loss Coefficient | <1x104 |
Thermal Conductivity | 1.4W/m ℃ | Performance of Quartz Tube |
detailed drawing
Production Process
Product Usage
