Factory direct supply high temperature electric furnace 1200℃ laboratory melting box furnace muffle furnace
-
$1600.00 / 1 - 2 pieces
$1400.00 / >=3 pieces - 1 piece
- Anhui Greestals Bio-Technology Co., Ltd.
- Anhui, China
- Mr Peter Wang
Product Detail
| appearance: | Muffle furnace | Grade Standard: | Electronic grade, industrial grade |
| MF: | -- | Brand Name: | Gray Starrs |
| Origin: | Anhui, China | purity: | -- |
| EINECS Number: | -- | Payment Terms: | Letter of Credit, Telegraphic Transfer |
| application: | Melting and sintering | model: | SXL-1200C |
| CAS Number: | -- | Other Names: | Muffle furnace |
General information
The new SXL-1200C series muffle furnace has excellent technology, advanced and beautiful design, high reliability, and is an ideal equipment for high temperature sintering, metal processing, quality inspection, etc.
feature
Housing made of carbon steel for easy maintenance and excellent durability
Double shell reduces external temperature and improves stability
Ceramic fiber cavity with embedded resistance wire provides efficient heating
Internal over-temperature protection and thermocouple failure alarm
Safety cut-off when the door is opened during operation
PC communication 485 port
Technical Parameters
|
Model |
SXL-1207 |
SXL-1212 |
SXL-1236 |
|
|
Cavity volume |
7.2L |
12L |
36 Liters |
|
|
Internal dimensions (D x W x H) |
300x200x120 mm |
300x200x200 mm |
400x300x300 mm |
|
|
Voltage |
AC220V single phase 50/60Hz |
AC220V single phase 50/60Hz |
AC380V three-phase 50/60Hz |
|
|
strength |
3 kW |
4 kW |
8 kW |
|
|
temperature |
Maximum 1200℃ Maximum continuous operating temperature 1150°C |
|
||
|
Temperature Controller |
Digital PID controller with self-tuning function 30 programmable segments Accuracy +/- 1°C |
|
||
|
Heating elements |
Resistance wire |
|
||
|
Temperature Sensor |
N-type |
|
||
|
Heating rate |
Recommended <10°C/minute Maximum 30℃/min |
|
||
|
Cooling rate |
Up to 10°C/min, over 700°C |
|
||
packing list
|
thing |
Name |
quantity |
|
|
1 |
Oven Mitts |
1 pair |
|
|
2 |
Crucible Tongs |
1 |
|
|
3 |
User Manual |
1 |
|
|
4 |
Certificate |
1 |
|
|
5 |
Warranty card |
1 |
|
