Factory direct supply high temperature electric furnace 1200℃ laboratory melting box furnace muffle furnace

Product Detail

appearance:Muffle furnaceGrade Standard:Electronic grade, industrial grade
MF:--Brand Name:Gray Starrs
Origin:Anhui, Chinapurity:--
EINECS Number:--Payment Terms:Letter of Credit, Telegraphic Transfer
application:Melting and sinteringmodel:SXL-1200C
CAS Number:--Other Names:Muffle furnace

General information

The new SXL-1200C series muffle furnace has excellent technology, advanced and beautiful design, high reliability, and is an ideal equipment for high temperature sintering, metal processing, quality inspection, etc.

feature

Housing made of carbon steel for easy maintenance and excellent durability

Double shell reduces external temperature and improves stability

Ceramic fiber cavity with embedded resistance wire provides efficient heating

Internal over-temperature protection and thermocouple failure alarm

Safety cut-off when the door is opened during operation

PC communication 485 port

Technical Parameters

Model

SXL-1207

SXL-1212

SXL-1236



Cavity volume

7.2L

12L

36 Liters



Internal dimensions (D x W x H)

300x200x120 mm

300x200x200 mm

400x300x300 mm



Voltage

AC220V single phase 50/60Hz

AC220V single phase 50/60Hz

AC380V three-phase 50/60Hz



strength

3 kW

4 kW

8 kW



temperature

Maximum 1200℃

Maximum continuous operating temperature 1150°C



Temperature Controller

Digital PID controller with self-tuning function

30 programmable segments

Accuracy +/- 1°C



Heating elements

Resistance wire



Temperature Sensor

N-type



Heating rate

Recommended <10°C/minute

Maximum 30℃/min



Cooling rate

Up to 10°C/min, over 700°C



packing list

thing

Name

quantity



1

Oven Mitts

1 pair



2

Crucible Tongs

1



3

User Manual

1



4

Certificate

1



5

Warranty card

1
