Custom Crystal Quartz Glass Clear Fused Silica CNC

Product Detail

Edge processing:finely polished edgesbrand:not any
Operating temperature:1100 degrees CelsiusOpaque quartz plates:Available in clear and opaque quartz plates
Thickness Tolerance:0.02mmMaterial:SIO2>99.99% fused silica
size:client needsSupply capacity:300 pieces per day
Processing services:Bending, welding, cuttingPackage preview:
thickness:0.1-200mmQuartz processing:Welding and Machining
application:Optics/Semi-finished Products/Industrialshape:round shape
Surface Quality:60/40 Quartz Sleeveport:Shanghai
payment terms:Western Union, D/P, D/A, T/TApplication 2:chemical industry
type:Transparent Quartz PlateApplication one:optical quartz window
Origin:Jiangsu, ChinaPackaging Details:Customized according to customer requirements
model:Quartz plate disc
product description
CNC machining of quartz products
GLS Quartz supplies fused silica plates from a standard stock range or custom sizes and options. Fused silica plates are widely used in industry and science because of their optical and mechanical properties. These properties make it resistant to chemicals, high temperatures and thermal shock. These include large quartz plates with an area of ​​1 square meter to protect delicate optical window devices with multi-layer coatings. It is machined into custom designs in various shapes and thicknesses.
List of functions
Properties of Fused Silica
* High temperature resistance
* High chemical purity
* High corrosion resistance
* Wide range of light transmission, from UV to IR
* Excellent electrical performance
insulation quality
* Very low coefficient of thermal expansion
* Very high hardness
* permeability
* Remarkable stability under atomic bombing



Processing machinery
Full CNC Capabilities
CNC engraving and milling machine
OD and ID Grinders
grinding and polishing
core drilling
External polishing
centerless grinding
Multi wire sawing machine
Laser Grinding/Grinding
laser
pitch polishing
Wire cutting machine
Face milling cutter
slice saw
boring
water jet
product specification
Quartz disk
(stock available)


Quartz Ground Plates - Regular Stock Sizes
10*1mm quartz disk
1" X 1" X 1/16" thick quartz plate
3" X 3" X 1/4" Thick Quartz Plate
12*1mm quartz disk
1" X 1" X 1/8" Thick Quartz Plate
4" X 4" X 1/16" thick quartz plate
15*1mm quartz disk
1" X 1" X 1/4" Thick Quartz Plate
4" X 4" X 1/8" Thick Quartz Plate
15*1.5mm quartz disk
1.5" X 1.5" X 1/16" thick quartz plate
4" X 4" X 1/4" Thick Quartz Plate
20*1mm quartz disk
1.5" X 1.5" X 1/8" thick quartz plate
5" X 5" X 1/16" thick quartz plate
20*1.5mm quartz disk
1.5" X 1.5" X 1/4" thick quartz plate
5" X 5" X 1/8" thick quartz plate
19.4*2mm quartz disc
2" X 2" X 1/16" thick quartz plate
5" X 5" X 1/4" Thick Quartz Plate
25*1mm quartz disk
2" X 2" X 1/8" thick quartz plate
6" X 6" X 1/16" Thick Quartz Plate
30*1mm quartz disk
2" X 2" X 1/4" Thick Quartz Plate
6" X 6" X 1/8" Thick Quartz Plate
30*2mm quartz disk
3" X 3" X 1/16" thick quartz plate
6" X 6" X 1/4" Thick Quartz Plate
36*2.2mm quartz disk
3" X 3" X 1/8" thick quartz plate

consistency
various precise thicknesses
Processing according to design
labware optical lens
Electronic industry medical components
Aerospace Chemicals
