high quality graphite sheet

Product Detail

application:mechanical EngineeringSupply capacity:20,000 tons/year
Material:High purity graphiteproduct name:graphite foil
payment terms:L/C, D/A, D/P, T/T, Western Unionport:Beijing, Tianjin, Shanghai, Qingdao
Packaging Details:Carton, wooden boxOrigin:China
chemical composition:Carbon>99%grade:industrial grade
type:soft boardcolor:Black
Name:graphite partsHardness (Shore A):85
Product Description

After the natural flake graphite is screened and pickled, the treated graphite expands more than 100 times, and is floated and pressed into graphite paper, that is, flexible graphite

Flexible graphite is mainly used in the sealing industry. Flexible graphite sheets are mainly used in electric power, petroleum, chemical and other industries. Flexible graphite paper in these industries is mainly used for sealing of machines, pipelines, pumps, and valves.

Graphite foil is the basis of a new type of sealing material, which has the characteristics of high temperature resistance, corrosion resistance, radiation resistance, good electrical and thermal conductivity, good compression rate, rebound rate and low stress relaxation rate, etc.

Graphite foil:

Graphite foil and graphite sheets are used for mechanical seals.

Graphite ribbon:

Graphite tape is used for thread sealing and sealing flanges.

Adhesive graphite foil:

Graphite foil and tape are mainly used for thread and flange sealing.

parameter thing
graphite foil Graphite reinforced plate 304 Graphite reinforced plate 316
Carbon content (%) 95~99.9 can be ≥99 ≥99
Resistivity (μΩ-m) 3~7   3~7
Sulfur content (ppm) 0~1200 can be ≤1100 ≤1200
Dichlorine content (ppm) ≤35 ≤50 ≤40
Compressive strength (Mpa) ≥160
Bending strength (Mpa) ≥4.5
Tensile strength (Mpa)   ≥40 ≥40
Density (g/cm3) 1 +- 0.05 1.25 +- 0.05 1.25 +- 0.05
Compression modulus ≥40% 30~35% 30~35%
Modulus of resilience   10~12% 19%
