High quality free sample graphite sheets
- $2.80 / >=1000 kilograms
- 1000 kilograms
- Langfang Fangdun Fireproof Sealing Material Co., Ltd.
- Hebei, China
- Mr Qinghe Wang
Product Detail
| Supply capacity: | 10000 packs per month | type: | Reinforcing plate |
| C content (%): | 95% | application: | seal |
| brand: | Shield | Carbon content: | 95% |
| color: | Black | Packaging Details: | wooden box |
| grade: | industrial grade | Density Tolerance: | ±0.06g/cm3 |
| tensile strength: | ≥4MPa | Origin: | Hebei |
| port: | Tianjin | payment terms: | L/C, Western Union, D/A |
| model: | Gra-01 |
Product Description
High quality graphite flakes
describe:It is made of high-carbon phosphorus flake graphite through chemical treatment and high-temperature expansion rolling. It is the basic material for manufacturing various graphite seals.
The main purpose:Widely used in dynamic and static sealing of machines, pipelines, pumps and valves in industries such as electric power, petroleum, chemical industry, instrumentation, machinery and diamond. It is an ideal new sealing material to replace traditional seals such as rubber, fluoroplastics, and asbestos.
data sheet
|
thing |
N level |
industrial grade |
|
Density tolerance g/cm3 |
±0.05 |
±0.06 |
|
Carbon content≥% |
99.5 |
95 |
|
Tensile strength≥Mpa |
5 |
4 |
|
Compression ratio≥% |
30 |
30 |
|
Recovery rate≥% |
15 |
15 |
|
Sulfur content≤% |
400 |
1200 |
|
Chlorine content≤% |
25 |
50 |
|
Stress relaxation rate % |
10 |
10 |
|
Burning loss≤% |
0.5 |
2 |
temperature: -240~1650℃ (under non-oxidizing environment)
-200~850℃ (under oxidizing environment)
|
thing |
sheet |
roll |
|
Density g/cm3 |
1 |
1 |
|
Length mm |
1000, 1500mm |
30~100 meters |
|
Width mm |
1000, 1500mm |
1000~1500 |
|
Thickness mm |
0.5~5 |
0.2~1.1 |
